Items | Parameters |
Model No. | LJ_SEN3001 |
Torque sensor mode | Strain gauge torque rotational coupled transmission |
Sensitivity | >16 mV / kg |
Min. Detected value | 1kg |
Max detected value | 30kgs |
Deviation (0-2kgs) | 0.5kgs |
Torque sleeve loading (continuous) | 150kgs |
Torque sleeve loading (instant) | 300kgs |
Fatigue cycles | 100000 times |
Post-fatigue deviation | < 10% |
Water-proof | IP56 |
Input voltage | 12-45V |
Input current | <0.1A |
RPM signal | >32Hz |
RPM forward running signal | >3V |
RPM forward running signal | <0.5V |
Pedaling output benchmark | 0.4V |
Sensitivity output | 1.2-1.7º |
Pedaling output signal mode | Analog signal |
Pedaling signal delay | <30ms |
Pedaling signal transmission | Wireless power carrier mode |
Pedaling signal output frequency | 200Hz |
Pedaling signal frequency range (0-30kg) | 50-2000Hz |
Pedaling signal drifting (<) | ±0.5Hz |
