产品详情
* High power efficiency
* High current output: 500W 10A
* Wide DC input range: 24-48V
* Hall-free booting or Hall booting
* PID speed closed-loop control
* smooth responding curve
* Low noise
* Sinusoidal vector control
* Low power consumption
* High efficiency
* RS485 communication
* Long-distance dynamic data monitoring
* Local portal control and indication
* Manually adjust speed available
* Applications: 3D printing, carving,
medical equipment, label machine, packing machine,dispensing machine
Items | Parameters | |
Model No. | SB_ESC4810 | |
Input | Working voltage | DC 24-36-48V |
Working current | 10A MAX. | |
Peak current | 20A | |
Static current | 0.2A (24V) | |
Booting mode | Hall | yes |
Hall-free | boot | |
Output | Output power | 500W AT 48V MAX |
rotation speed | 9000RPM | |
Monitoring | Communication | RS485 |
Status monitoring | Negative pole | Earth wire |
Reversion control (F/R) | yes | |
Braking control（BRK) | yes | |
Enable control (EN) | yes | |
SV output voltage | linear | |
PG | yes | |
Alarm | 5V 10MA | |
Negative pole | 5V 0.1A | |
Rotating speed adjustment | 500-9000RPM | |
Protections | Reversion | yes |
Low voltage | yes | |
Over current | 10A | |
Over temperature | yes | |
Mechanical | Weight | 250g |
Measurements | 118*76*35mm | |
Water-proof | IP20 | |
